Product Attribute:
Type:lithium
Capacity:101 - 150AH
Voltage:3.2V
Size:46*182*295mm(cell)
Place of Origin:Guangdong China (Mainland)
Brand Name:GeePower
Model Number:GPLFP46182295/100Ah
best car battery brands:professional lithium ion world best brand
Certification:CE,UN38.3,MSDS
Aplication:Electric car, bus
Impedance:< 0.5 mΩ
Specific Energy:110Wh/Kg
Volumetric Specific Energy:162Wh/L
Environment:Non-toxic
Security:No fire,no explosion,no leakage
Lifespan:>2000 times
Welcome:sample order
Production Description:
Product Description
professional lithium ion world best car battery brands,car battery brand names
(can be assembled into various packs, any voltage and capacity are available.)
3.2V 100AH LiFePO4 battery data sheet
| Item No. | Voltage | Capacity | battery type | Lifespan | Impedance | Specific Energy | Dimensions | Weight |
| GPLFP46182295/100Ah | 3.2v | 100AH | LiFePO4 | >2000 cycles | < 0.5 mΩ | 110Wh/Kg | 46*182*295mm | 3.3kgs |
3.2v 100ah lifepo4 battery Characteristics
1. Soft polymer pack, no need for safety valve;
2. With reduced electrolyte,further enhancing battery safety and being able to be positioned in any direction;
3. Low internal resistance,less than 0.5 mΩ
4. Flexible design to meet customer's unique requirement;
5. Basic cells are mass produced and easy to build stable and consistent large capacity battery packs;
6. Suitable for high rate charge and discharge.
3.2v 100AH LiFePO4 battery detailed specification
| Model | GPLFP46182295/100AH |
| Nominal Capacity | 100AH |
| Impedance | <0.5mΩ |
| Specific Energy | 110wh/kg |
Volumetric Specific Energy | 162wh/l |
| Weight | 3.3kg |
| Voltage | Norminal voltage | 3.2V |
| Charge voltage(CC-CV) | 3.65V |
| Discharge cut-off voltage | 2.5V |
| Discharge current | Max. charge current | 3C5A |
| Standard charge current | 0.3 C5A |
| Max. dicharge current | 3C5A |
| Max. pulse dicharge current | 10C5A |
Charge current (CC-CV) | Max. charge current | 3C5A |
| Standard charge current | 0.3 C5A |
| Fast charge: 10min/50%, 30min/80%, 60min/100% |
Operating Temperature | Charge | 0°c ~ 45°c |
| Discharge | -20°c ~60°c |
| Storage | -10°c ~ 45°c |
| Lifespan | 80% DOD > 2000times |
| 70% DOD > 3500times |
Temperature Resistance of case | Max. constant temperature | 135°c |
| Instant temerature | 170°c |
| Self discharge Rate | <3%(per month) |
Pitures and dimensions
Performance testing graph
GeePower battery safety testing(No fire, no explosion,no leakage)
GeePower battery safety performance
| Item | Test name | Result |
| 1 | Over charge | No fire,no explosion |
| 2 | Over discharge | No fire,no explosion |
| 3 | Short Circuit | No fire,no explosion |
| 4 | Drop | No fire,no explosion,no leakage |
| 5 | Hot oven | No fire,no explosion |
| 6 | Crush | No fire,no explosion |
| 7 | Needle puncture | No fire,no explosion |
Company Information
Why choose GeePower Battery?
GeePower battery production process
Our Services
Battery quality control for after-sale
All of GeePower battery cells in a pack are with very high consistency.In a pack, each cell has its own sole electronic code(ID number) for quality control after-sale. Assume one cell in a pack is damaged in any reason after several years later, we could provide a exactly same cell to the client to replace this damaged one(same voltage, capacity, impedance,etc.), in order to make sure all of the cells in this pack with very high consistency. GeePower has a strong system working for this.
GeePower Customer Feedback
The batteriess are even better than expected and expectations, very good.----Antonio(from Livorno, Italy)
We are happy with your battery quality. I've also been very happy with your good service,
let's continue discussions and work on more,tks.----Michael (from Berlin,Germany)
Warranty
more than 2 years(base on different application)
Trade term
FOB Shenzhen,Guangzhou or Hongkong; EXW, CIF,DDU and DDP are available
Delievery and Sample
10 - 25 working days for mass order.
Sample is avaliable and welcome.
Packaging & Shipping
Packing
| Product name | Item No. | QTY | Carton box dimensions(mm) | Gross weight(kg) |
| Length | Width | Height |
| 100AH Battery cell | GPLFP46182295 /100Ah | 2 | 360 | 150 | 330 | 7 |
Trading process
Trade with
Shipping way
please send message to us through the table as below for getting more info about this product,other customized projects,detailed quotation,or various trade terms. Our team is ready to support you.
Thanks for your time.
