Auto
Main technical parameters: 1. Rated output power: 7.5KW 2. Test rang of rail pressure: 0-1800bar 3.Test precision of rail pressure: ±2Mpa 4.Test temperature of test oil:40±2 5. Filter precision of test oil: less than 5 6. Capacity of tank: 28L 7. Dimension: 1200X560X1650MM 8. Aggregate weight: 350KG 9.Electricity: 380V, 50Hz, 3 phase Functions: 1. High pressure washing: faults caused by pollution from oil injector can be renovated. 2. Injection quantity test: injection volume and return volume of injector in different working conditions such as Full-loaded,Idling status ,Pre-injection ,Leak test etc can be detected, observe oil mass through measuring jup, compared with initial standard data. Monomial and overall property of injector can be judged automatically 3. Atomization test: Observe atomization effect of injector nozzle and judge whether the orifice is obstructed. 4. Sealing performance test: check whether nozzle, nozzle cap nut and electromagnetic valve body leak oil. 5. Inquiry, store and print data and custom information Characteristics of equipment: 1. Computer control, 10.4 inch liquid crystal rolling display, touch-type operation. 2. Oil volume displayed through measuring cup and realize half close-loop control. 3. Original Bosch common-rail pump and pressure rail system are provided according to CP1 standard. 4. Identical rotation speed can realize the functional tests of oil injector. 5. Precision measurement, simple operation, low noise, and energy conservation.
