CR-NT819B Common Rail Injection Pump Test Bench

CR-NT819B Common Rail Injection Pump Test Bench

Typical Clients:  Universal

Market Type:  OE Market

Product Attribute:

Typical Clients:

Universal

Production Description:

CR-NT819BCommon Rail Test Bench
Main technical parameters:
1. Rated output power: 11KW, 15KW
2. Oil pump rotation speed: 0-3500rpm
3. Test rang of rail pressure: 0-2000bar
4. Test precision of rail pressure:±0.6Mpa
5. Test precision of flow sensor: 0.6%
6. Temperature of test oil:40±2
7. Filter precision of test oil: less than 5μ
8. Capacity of heavy tank: 80L
9. Dimension: 1760X830X1650MM
10. Aggregate weight: 800KG
11.Electricity: 380V, 50Hz, 3 phase or 220V, 60 Hz, 3 phase

Functions:


  1. Full-automatically test common rail pumps in following aspects:
Injection volume, return volume
Pump chamber pressure
Oil supply pressure
Sealing performance
Functions of ZME valve
2.Equipped China-made flow sensor to test injection and backflow under the following status:
 Full-loaded
 Idling status
 Pre-injection
 Leak test

  1. Pump nozzle and electronic unit pump can be tested through adaptor and additional system.
  2. Test electronic high pressure oil pump such as VP37 VP44 by means of additional system.
  3. Windows system and humanized operating procedure, client can add data by himself, save printed data and customer information.
  4. Multi-machine network and remote control are available.

Equipment Characteristics:

  1. High degree automation: Automation applied in product detection.
  2. High import configuration: takes up 50% of equipment cost.
  3. Flow sensor for implementation of the oil mass detection and full closed-loop control.
  4. Compact universal test bench can successively complete test for 4-6 injectors in one setup.
  5. Remote monitoring is convenient for service and software upgrading.
