1800kg CE Wheel Loader ZL18F

Product Attribute:

rated load:1800kg

total weight:4100kg

rated bucket capacity:0.85 m3

Overall Dimensions (L x W x H):5300*1820*2760 mm/6500*1820*2800

engine model:WEICHAIHUAFENG ZHBG41

rated power:47kw

Applicationt:

4 wheel drive wheel loader

Production Description:

1 .Rated Load                                                          1800 kg
2. Total Weight                                                        4100 kg
3. Rated Bucket Capacity                                   0.85 CBM
4. Max. Tractive Force                                          40 KN
5. Max. Breakout Force                                                43 KN
6. Max. Gradeability                                             38°
7. Max. Dumping Height                                              2800 mm / 3100 mm
8. Max. Dumping Reach                                                         1050 mm / 1000 mm
9. Raising Time                                                        5.0 s
10. Total Cycle Time                                              9.5 s
11. Overall Dimensions (L x W x H)                  5300*1820*2760 mm / 6500*1820*2800
12. Min. Turning Radius                                      3200 mm
13. Engine Model                                                    WEICHAI HUAFENG ZHBG41
14. Engine Type                                                       Four-cylinder, Inline, Water-cooled, Four-stroke Diesel Engine
15. Engine Rated Power                                       47 kW
16. Engine Rated Speed                                       2400 rpm
17. Engine Min. Fuel Consumption Ratio         258.4 g/kWh
18. Transmission System                                               ZL265 Integrated/Split Hydraulic Torque Converter
19. Gear Shift                                                          1 Forward, 1 Reverse, 1 High Speed, 1 Low Speed
20. Max. Speed                                                       25 km/h
21. Model of Drive Axle                                        ZL16 Hub Reduction Axle (small)
22 . Wheel Tread                                                     1480 mm
23. Wheel Base                                                       2150 mm
24. Drive Mode                                                       4-wheel Drive
25. Hydraulic System Working Pressure         20 Pa
26. Fuel Tank Capacity
