rated load:1500kg
total weight:3450kg
Rated Bucket Capacity:0.7 m3
Overall Dimensions (L x W x H) :5060*1690*2630 mm
wheel loader
1 .Rated Load 1500 kg 2. Total Weight 3450 kg 3. Rated Bucket Capacity 0.7 CBM 4. Max. Tractive Force 30 KN 5. Max. Breakout Force 32 KN 6. Max. Gradeability 38° 7. Max. Dumping Height 2800 mm 8. Max. Dumping Reach 1000 mm 9. Raising Time 5.0 s 10. Total Cycle Time 9.5 s 11. Overall Dimensions (L x W x H) 5060*1690*2630 mm 12. Min. Turning Radius 3200 mm 13. Engine Model XINCHAI A498BT1 (EURO III) 14. Engine Type Four-cylinder, Inline, Water-cooled, Four-stroke Diesel Engine 15. Engine Rated Power 36.8 kW 16. Engine Rated Speed 2400 rpm 17. Engine Min. Fuel Consumption Ratio 230 g/kWh 18. Transmission System ZL265 Integrated Hydraulic Torque Converter 19. Gear Shift 1 Forward, 1 Reverse, 1 High Speed, 1 Low Speed 20. Max. Speed 25 km/h 21. Model of Drive Axle ZL16 Hub Reduction Axle (small) 22 . Wheel Tread 1400 mm 23. Wheel Base 2150 mm 24. Drive Mode 4-wheel Drive 25. Hydraulic System Working Pressure 16 Pa 26. Fuel Tank Capacity
