fully-automatic bus climate control panel air conditioner yutong bus ac control panel

Product Attribute:

Supply Ability:2000 Piece/Pieces per Month

Production Description:

CK200201 fully-automatic bus climate control panel air conditioner yutong bus ac control panel:

Newbase self-design, develop, manufacture controller. (Patent product)

Newbase design and develop this controller  for YUTONG bus. Now it have been wide used by kinds of vehicle around the world.

It is the most Comprehensive bus ac Electric Control Device. This panel including function keys including automatic control,

refrigeration, fresh air, self-test, power-down memory,  fault alarm display, Interior& Exterior temperature, multi-stage air volume adjustment, over-voltage automatic protection, and the second function etc.

Technical Parameters

Temperature Range: 15-32°C

Working Voltage: DC24V (DC20 +1 V ~ 32 +1 V)

Temperature and humidity range: -30 °C -80 °C, 5% -95% RH non-condensing environment

Storage temperature and humidity range: -10 °C -70 °C, 5% -95% RH non-condensing environment

Input:

1) Return air temperature sensor (25 ° C, Rb = 5K, B = 3274);

2) Defrost temperature sensor (25 °C, Rb = 5K, B = 3274);

3) Pressure sensor;

4)Power (Generator Power Detection);

5) Auto power source (battery);

6) Backlight power;

Output:

1) Condenser fan (maximum 300mA);

2) High wind speed (maximum 300mA);

3) Wind Speed (maximum 300mA);

4) low speed wind (maximum 300mA);

5) Fresh Air open (maximum 300mA);

6) Fresh Air off (maximum 300mA);

7) Compressor clutch (maximum 300m A);

8) Excitation (maximum 3)

Dimensions:
