Wall Washer Lamp Adhesive Machine

Wall Washer Lamp Adhesive Machine

Application:  Acura, Alfa romeo, Aston ...

Market Type:  After Market

Packing:  Wood

Samples:  Not Available

Maximum Prodcution Capacity:  100 Sets/Month

Delivery Time:  25 Days

Place of origin:  China

Export Ratio:  11% - 20%

Price Terms:  FOB

Delivery Port:  Shenzhen Or Guangzhou

Minimum Order:  1Set/Sets

Product Attribute:


Acura, Alfa romeo, Aston martin, audi, Aux, Baolong, Beiqi, Bentley, BMW, Bugatti, Buick, BYD, cadillac, Changan, Changfeng, Chery, chevolet, Chrysler, Citroen, Changhe Auto, Dadi, DAEWOO, Daihatsu, Dodge, Dongfeng, DADI Auto, Ferrari, fiat, Ford, Foton, Fuqi, Geely, GMC, Gonow, Great wall, Hafei, HAMA, Honda, Hongqi, Huandai, Huizhong, Hummer, Hyundai, Huanghai Auto, Infiniti, iveco, Jaguar, Jeep, Jinbei, JMC, JAC, Kia, Lamborghini, Land rover, Landwind, Lexus, Lincoln, Lotus, Maserati, Mazda, Mercedes Benz, MG, Mini, Misubishi, Mitsubishi, Monaro, Nissan, Peugeot, Spyker, Suzuki, Tianma, Toyota, Toyota

Production Description:

In case you have interest,please don't hesitate to send us an enquiry at: sales.gzdh(2)gmail.com Skype:amy.cn86

Machine operating distance: 700 x 700 x 20, also can be customized according to customers requirement
Glue mixing proportion: 1:1, 10:1 and other fixed proportion.
Stirring way: static mixing, and also can choose dynamic mixing.
Supplying method: High precision gear pump.(can match ram pump if required)
Moving trail: dot, straight-line, frame, pulse signal and other moving track
Glue pouring quantity: 10-60g/5s, except special type.
Moving speed: 0-300mm/s
Position accuracy: ±0.02mm
Mixing accuracy: ±1%
Dispensing glue Precision: ±1%
Capacity of container: A 30L, B 10L, can be customized.
Working voltage: AC220V50-60Hz
Working pressure: 0.5-0.7Mpa
Overall dimension: L1200mm x W1200mm x H1500mm
Machine weight: about 450Kg

2, Main Feature:
A, matching accuracy, mixing and pouring all in one, complete the real full automation
B, well-proportioned mix, avoid waste by manual operation
C, position accuracy, fast speed, convenient adjustment
D, good generality, conventional voltage, power, transformer, ignition coil, high voltage ignition coil, reverse sensor, circuit board can be applied. It need to be cleaned when change glue.
E, easy programming, easy operation and anyone can operate
F, tally function, non-standard mode, primer mode, level alert, filter mode, flow display device, preventing backflow device and other functional device. It can be added other function if customer requires.

3, Industry and Glue Application:
Industry: voltage, power, transformer, ignition coil, high voltage ignition coil, reverse sensor, circuit board, other electronic products and LED products which applied in potting process.
Glue: epoxy, silica gel, AB glue, PU and other glue which need matching

4, Optional Function
A, evacuation
B, heating function
C, change other pump of supplying glue
D, add motion board and made moving diversification
