RS62 Series Multi-voltage Photoelectric Sensor Description
12-240 VDC or 24-240 VAC
SPDT Relay Models
Accurate Detection
Modes | Ranges |
Through Beam | 10 ~ 30m |
Retroreflective | 5 ~ 7m |
Diffuse | 700mm |
Through-beam | Diffuse | Retroreflective | Retroreflective with Polarizing Filter | |
Operating Range | 30m (98.4 ft.) | 700mm (27.56 in.) | 7m (22.9 ft.) | 5m (16.4 ft.) |
Part Numbers | ||||
Emitter | RS62-T030MD-EY9C2L2 | |||
SPDT Relay (Light On) | RS62-T030MR-LY9C5L2 | RS62-D0700R-LY9C5L5 | RS62-L7000R-LY9C5L5 | RS62-L5000R-LY6C5L5-PF |
SPDT Relay (Dark On) | RS62-T030MR-DY9C5L2 | RS62-D0700R-DY9C5L5 | RS62-L7000R-DY9C5L5 | RS62-L5000R-DY6C5L5-PF |
Technical Data | ||||
Power Supply | 12...240 VDC or 24-240 VAC ± 10% | |||
Current Consumption | 2 VA max | |||
Light Emission | Infrared (Through-beam, Diffuse & Retroreflective) or Modulated Red LED (Polarized Retroreflective) | |||
Setting | Continuously variable adjuster (except for long range through-beam and retroreflective models) | |||
Indicator LEDs | Red LED: Operation Indicator, Green LED: Stability Indicator | |||
Output (Relay contact 1c) |
* Switching capacity: 250 VAC 1A (resistive load) 30 VDC 2A (resistive load) * Electrical life: 100,000 or more operations (at rated AC load) 50,000 or more operations (at rated DC load) * Mechanical life: 100,000 or more operations |
|||
Response Time | 10 ms max. | |||
Switching Frequency | 10 Hz max. | |||
Connection | 2 meter cable | |||
Mechanical Protection | IP66 | |||
Housing Material | Housing: ABS, Lens: Polycarbonate | |||
Operating Temp. | -20...+55°C (-4...+131°F) | |||
Reference Standard | EN 60947-5-2 |
