Quick Details

• Output Power:

  4kw

• Length:

  2.4m

• Width:

  4.4m

• Height:

  2.1m

• Output voltage:

  220V

• Function:

  Filling Clothes

• After-sales Service:

  Local Agent And Engineers

• Model No:

  818B

• Place of Origin:

  China

• Delivery Time:

  20days

• Packing:

  Plywood

• OE Experience:

  No

Product Name:Automatic Down Jacket Filling Machine

Automatic Down Jacket Filling Machine

Application

Acura

Product Description:

More Convenient

Down-filling data can import and export directly by USB (optional), there's unnecessary for manual input.

Increased one-touch operation, down-outing, down-going and peeling process can be one step; do not need press the button many times.

One-piece design of the weighing system makes that it can adjusts freely on back and forth, up and down, and convenient to install & maintain.

Brand: Bealead

Model: 828B

Composed by: 1 feeding unit and 2 weighing units/ filling station

Filling Pipes: 2

Scales by filling pipe: 4

Fillings by hour: 1800( Polyester Balls)/ 1400( Down)

Application: Apparel, Commodity, Textiles

Material Application: 50%- 90% down

Weight: 1300kg

Filling Storage: 13kg

Weighing Range: 0.2g- 20g

Accuracy: 0.001g

Feeding Unit Size: 2.4* 1* 2.1m

Weighing Unit Size: 2.15* 0.7* 1m

Overall Size: 2.4* 4.4* 2.1m

Min. Site Area: 5m* 6m

ChangShu Bealead Automatic Machine Co.,LTD, located in changshu, jiangsu ,china. Close to ShangHai Port, driving for 1.5hours, transportation convenient.

Our company is R&D manufacturer of intelligent device for clothing production. We are in leading

position in Down feather filling area, covered most of Chinese market, Bosideng, Luo Lai, UNI QLO, are our customers.

We also have agents overseas, and more than 20 technecians for after sales service. They could answer you and service you at the first time you need.
