Wrapped V-Belt,Classical V Belt Z(O,M),A,B,C,D,E,F

Applicationt:

auto

Production Description:

Product Details:

Standard or Nonstandard	Standard
Type	V-belt
Material	Rubber
Place of Origin	Zhejiang, China (Mainland)
Brand Name	Baihua or client's brand
Model Number	Z(O,M),A,B,C,D,E,F
color	black
Certification	ISO9001:2008
Factory	Li

Detailed Product Description
classical wrapped v belt
1.with high strength.
2.with low protraction.
3.small matching tolerance.



type	top wideh	pitch width	height	length conversion	length range (inch)	length range(mm)	mark
Z	10	8.5	6	Li=Lw-22	13''-120''	330-3048	Li
A	13	11	8	Li=Lw-30	14''-394''	356-10008	Li
AB	15	12.5	9	Li=Lw-35	47''-394''	1194-10008	Li
B	17	14	11	Li=Lw-40	19''-600''	483-15240	Li
BC	20	17	12.5	Li=Lw-48	47''-394''	1194-10008	Li
C	22	19	14	Li=Lw-58	29''-600''	737-15240	Li
CD	25	21	16	Li=Lw-61	47''-394''	1194-10008	Li
D	32	27	19	Li=Lw-75	80''-600''	2032-15240	Li
E	38	32	23	Li=Lw-80	118''-600''	2997-15240	Li
F	50	42.5	30	Li=Lw-120	177''-600''	4500-15240	Li
