Standard Poly Rib V Belt

Applicationt:

auto

Production Description:

Product Details:

Standard or Nonstandard	Standard
Type	V-belt
Material	Rubber
Place of Origin	Zhejiang, China (Mainland)
Brand Name	BAIHUA or clent's brand
Model Number	PM
color	black

Detailed Product Description
our company mainly produce and export rubber v belt at good qualtityand competitive price!

Production Type	Pb	Min	Max	Height	Angle	Length Range(inch)	Length Range(mm)	Factory
PH	1.60	0.30	0.15	2.8-3.0	40			Le
PJ	2.34	0.40	0.20	3.7-4.1	40	13''-120''	330-3048	Le
PK	3.56	0.50	0.25	4.2-4.5	40	22''-120''	559-3048	Le
PL	4.70	0.4	0.40	6.8-7.2	40	50''-160''	1270-4064	Le
PM	9.40	0.75	0.75	15.5-16.0	40	100''-160''	2540-4064	Le



Note : the value of wedge distance and the belt height is for reference only. Accumulated error of wedge distance is an important parameter,but it is influenced by working tension of the belt and elastic modulus.



poly v belts are divided into industrial poly rib belts  with PH.PJ .PK,PL  and PMmodels and automotive poly rib belts of the PK model only
