DC-AFS014 VDO Supplier Mass Air Flow Sensor 0280217503 For ALFA ROMEO / OPEL / SAAB / VAUXHALL

Application: ALFA ROMEO, OPEL, SAAB, ...

Market Type: After Market

Packing: 1PC/Box,30Boxes/Carton Buddle Bag And White Box Buyer Package Is Acceptable Size:603440cm

Samples: Charge

Maximum Prodcution Capacity: 20000 Pieces Per Month

Delivery Time: 5-7 Days

Quality Certification: TS16949

Place of origin: Wenzhou, Zhejiang

Export Ratio: 91% - 100%

Unit Price: USD US$12-18/Piece

Price Terms: FOB

Delivery Port: Ningbo / Shanghai

Payment Terms: T/T

Minimum Order: 100Piece/Pieces

Language Translator

Product Attribute:

Work Voltage:14V DC

Electric Current:≤350mA

Output Voltage:0~5V

Accuracy:≤3%

Response Time:≤15ms

Application Temperature:-40°C~+125°C

Applicationt:

ALFA ROMEO, OPEL, SAAB, VAUXHALL

Production Description:

ITEM NO.: DC-AFS014

REF NO.:
BOSCH 0280217503

OEM NO.:

ALFA ROMEO / FIAT / LANCIA 60589472
HOLDEN 90 510 156
IVECO 8024221 / 98439687
OPEL 90 411537 / 90510156
SCANIA 4239034

APPLICATION FOR:
ALFA ROMEO 168 (164) 3.0 / 3.0 24V Q4 / 3.0 24V QV
SAAB 900 11 Convertible 2.5 24 V6
OPEL CALIBRA A (85_) 2.5 i V6
OPEL OMEGA B (25_,26_,27_) 2.5 V6 / 3.0 V6
OPEL OMEGA B Estate (21_,22_,23_) 2.5 V6 / 3.0 V6
OPEL SINTRA 3.0 i 24V
OPEL VECTRA B (36_) i 500 2.5 / 2.5 i V6
OPEL VECTRA B Estate (31_) i 500 2.5 / 2.5 i V6
OPEL VECTRA B Hatchback (38_) 2.5 / 2.5 i V6
VAUXHALL CALIBRA 2.5 i V6
VAUXHALL OMEGA (B) 2.5 V6 / 3.0 V6
VAUXHALL OMEGA (B) Estate 2.5 V6 / 3.0 V6
VAUXHALL SINTRA 3.0 i 24V
VAUXHALL VECTRA (B) 2.5 i V6 / 2.5 i GSi
VAUXHALL VECTRA (B) Estate 2.5 i V6 / 2.5 i GSi
VAUXHALL VECTRA (B) Hatchback 2.5 i V6 / 2.5 i GSi

Mass Air Flow Sensor DC-AFS014
- Standard material according to technical drawings
- New Technology item available
- ISO/TS16949 Certification Approval

Hot-film Sensor Head:

It is our company independently developed by platinum

Main circuit:
96%AL2O3 aluminium ceramic board

Software adjust analog voltage through:
Bare chip import from Advanced Country

OUR ADVANTAGE:
1) Hot-film sensor head:
It is our company independently developed by platinum, material taken from American
well-known manufacturer of electronic slurry, in order to ensure the products have a
good temperature probe. (Temperature coefficient: 3850ppm; and response time 15ms)
have APPLY PATENT.
2) Aluminum Ceramics Substrate( 96% AL2O3 ):
with high dielectric constant substrate and good conductivity-temperature performance,
to ensure that the circuit perform stability in high-low temperature state. General factory
with using epoxy board (low prices),but Thermal performance is not very good .
3) The main circuit board:
Used the technical of thick film Hybrid Integrated Circuit, which is commonly used in
developed countries in the international area, thick-film resistors with higher resistance
accuracy (3%) and a smaller temperature coefficient (less than 100ppm).

DC-AFS014 VDO Supplier Mass Air Flow Sensor 0280217503 For ALFA ROMEO / OPEL / SAAB / VAUXHALL
