Product Attribute:
Voltage:DC 8-36V
G.W:2.6kg
Power:12-60w
Language:English/Chinese
Operating system:Linux
Video and audio input:4 channel
Video and audio out put:1 Channel RCA
Video compression:H.264
Video resulution:D1/HD1/CIF adjustable
Signal system:NTSC/PAL
Alarm input:8 channel
Alarm output:2 channel
Local storage:One SD card and one 2.5 inch 1TB HDD
Built-in modules:GPS+WIFI+3G(EVDO/WCDMA optional)
Applicationt:
Bus, Oil tanker, Logistic vehicle, Police car, Taxi, etc.
Production Description:
Features:
* CE,FCC certified
* Built-in G-sensor, GPS and 3G modules
* 4CH D1 audio and video input
* Resolution D1/HD1/CIF optional
* H.264 video compression
* Linux operating system* Dual-stream
* Digital watermarking functional
* 1HDD and 1SD card storage, HDD supports max 1TB,SD card supports max. 64GB
* Dynamic detection
* Acceleration statistics
* Hard disk auto-heating
* Unique patent in anti-vibration. 6pin connector for HDD housing and mainboard to ensure stable working under complex condition with vibration
* Data protection function of 8-second delay in cutting off the power, avoiding the loss of data and the corruption of storage file when the power is suddenly cut off.
* Rich peripheral interfaces, such as RS485, RS232, speed sensor interface,2 USB ports,1 E-SATA , RJ45 port and 1 CVBS&VGA.
* Support extension, such as control panel
* Car black box function, recording speed, position, momentum acceleration, temperature, brake, reverse, turning, alarm and other important information.
* DC8V ~ 36V wide voltage power supply,* Industrial standard embedded design
* Metal aluminum casing
* Low power consumption
* Operating temperature -25 to +85
Model Options
WP-CW2005-E: G-sensor + GPS + WIFI + 3G (EVDO)
WP-CW2005-E: G-sensor + GPS + WIFI + 3G (WCDMA)
