Product Attribute:
Voltage:12-36V
G.W:0.9kg
Power:6-12w
Language:Chinese/Eglish
Operationg System:Linux
Video and Audio input:4 Channel
Video and Audio output:1 Channel RCA
Video Compression:H.264
Video Resolution:D1/HD1/CIF adjustable
Audio compression:ADPCM
Alarm input:6 channel
Alarm output:2 channel
Storage:1 or 2 64GB(MAX) SD card
Built-in module:GPS and G-SENSOR
Applicationt:
Bus, Taxi, Truck, Police car, Oil Tanker, etc.
Production Description:
Features:
* CE,FCC certified
* GPS optional
* 4CH audio and video input
* Resolution D1/HD1/CIF optional
* H.264 video compression
* Linux operating system
* Dual-stream
* Digital watermarking functional
* SD card storage,max. 64GB each card
* Dynamic detection
* Data protection function of 8-second delay in cutting off the power, avoiding the loss of data and the corruption of storage file when the power is suddenly cut off.
* Rich peripheral interfaces, such as RS485, RS232, speed sensor interface
* Car black box function, recording speed, position, momentum acceleration, temperature, brake, reverse, turning, alarm and other important information.
* DC8V ~ 36V wide voltage power supply,
* Industrial standard embedded design
* Metal aluminum casing
* Low power consumption
* Operating temperature -25 to +85 degreesCelsius.
Model Options
|
Model |
BW1001-S1 |
BW1001-S2 |
BW1002-S1 |
BW1002-S2 |
|
Description |
1 SD Card |
2 SD Cards |
GPS
+
1 SD Card |
GPS
+
2 SD Cards |
