KIC 333-14513/14513U

Application: KIC

OEM No/Model: 333-14513/14513U

Market Type: After Market

Packing: Wood Pallet ; Waterproof Membrane;Reinforce The Package With Metal Straps

Samples: Charge

Maximum Prodcution Capacity: 20,000 Pcs Per Month

Delivery Time: 40 Days For New Models

Place of origin: China

Export Ratio: 11% - 20%

Price Terms: FOB

Delivery Port: Wuhan

Payment Terms: T/T

Minimum Order: 100PCS

Language Translator

Product Attribute:

Material:Gray Iron

Applicationt:

KIC

Production Description:

Application: KIC

OEM NO./Reference NO.  333-14513/14513U

1. Component::
C  3.0%-3.4%
Si  1.6%-2.2%
Mn  0.6%-0.9%
P  below 0.12%
S  below 0.12%
Cr   0.2%-0.6%
Cu 0.4%-0.8%

2. Friction surface hardness value: HB170-241
    Dynamic balance below  2000g.cm

3. Measurement
Brake face dia.:411mm
Over all depth:327mm
Brake face m
Hub pilot dia.:239mm
Flange thickness:12.7mm
Bolt circle dia.:285.75mm
Dust shield recess dia.:432.74mm
Overall dia.:482.6mm
Bolt hole No.-Dia.: 10x32.6mm, 5x14.29mm,

Package:
1.Qunatiy: 16 pcs per pallet
2.Package: wood Pallet ; waterproof membrane;reinforce the package with metal straps
