Inner diameter :80mm
Number of Row:Single Row
Bore Size:80mm
Outer Diameter :110mm
Size:13mm
Type:Roller Bearing
Material:Chrome Steel
Tolerance:P5
Clearance:C1
Another
NRXT8013DDC8P5 N series crossed roller bearings for the rotating joints of robots-THB Bearings THB N series Crossed Roller Bearings are thin-wall bearings consisting of an inner ring, a two-part outer ring, cylindrical rollers, and separators. The rollers are oriented at right angles to each other and kept apart by separators. This kind of N series Crossed Roller Bearings can sustain axial loads in both directions as well as radial loads and strong moment loads. And with their internal clearances factory-adjusted, it can be installed directly without troublesome shim adjustment. Mounting is facilitated by the outer ring parts being inseparable. Application: The rotating joints of robots Indexing mechanisms Rotary tables NRXT8013DDC8P5 technical specification: Bore diameter: 80mm Outer diameter: 110mm m Basic load ratings, dynamic: Cr=20.5KN Basic load ratings, static: Cor=32KN Mass: 0.38kg With seals on both sides, internal clearance: -0.010~0mm
