Inner diameter:60mm
Number of Row:Single Row
Bore Size:60mm
Outer Diameter:130mm
Size:51mm
Type:Ball Bearing
Material:Chrome Steel
Tolerance:P0
Clearance:C0
Another
THB Thrust ball bearings, two kinds: Single direction and double direction Single direction thrust ball bearings consist of a shaft washer, a housing washer and a ball and cage thrust assembly. The bearings are separable so that mounting is simple as the washers and the ball and cage assembly can be mounted separately. Single direction thrust ball bearings can accommodate axial loads in one direction and thus locate a shaft axially in one direction. They must not be subjected to any radial load. Smaller sizes are a available with either a flat seat surface on the housing washer or a sphered seat surface. Bearings with a sphered housing washer can be used together with a sphered seat washer to compensate for misalignment between the support surface in the housing and the shaft. Double direction thrust ball bearings consist of one shaft washer, two housing washers and two ball and cage thrust assemblies. The bearings are separable so that mounting is simple. Double direction thrust ball bearings can accommodate axial loads acting in both directions and can thus serve to axially locate a shaft in both directions. They must not be subjected to radial load. Cages: - a pressed steel cage, no designation suffix(a and b) - a one-piece machined brass cage, designation suffix M (c) - a one-piece machined steel cage, designation suffix F (d) - a two-piece machined brass cage, designation suffix M (e)
