Product Attribute:
Type:Diesel Engine
No. of Cylinders:6 Cylinder
Power:193KW/2200RPM
Displacement:9.726
Torque:1110/1300-1600
Place of Origin:Shanghai China (Mainland)
Brand Name:STEYR
Model Number:WD615
Warranty:2 Years
Production Description:
CHNTC STEYR WD615.61J WD615.67A WD615.68A DIESEL ENGINE FOR TRUCK
Hangzhou Engine Co., Ltd, China National Heavy-Duty Truck Group Shanghai stone diesel engine co.,ltd. (Hereafter referred to as Hangzhou Engine Co., Ltd, CNHTC)is currently the wholly owned subsidiary to China National Heavy- Duty Truck Group.
Model: WD615.61J
Application:For truck
series:WD615series
Type:in-line water cooling four strokes direct injection
Intake Mode:Turbocharging Intercooling
No. of Cylinder× Bore× Stroke(mm):6×126×130
Total Displacement(L):9.726
Rated Power/ Speed (kW/r/min):177/2400
Peak Torque/Speed(N.m/r/min):780/1500-1600
Torque Rise(%):10.75
Fuel Consumption at Rated Conditions(g/kW.h):220
Min. Fuel Consumption(g/kW.h):210
Oil Consumption(%):≤0.6
Max. Rated Speed Without load(r/min/):2640
Stable Idle Speed(r/min/):600±50
Noise(A):≤118
Max. Smoke at Full load(Rb):≤3.5
Smoke at free accelerate(Rb):≤3.5
Emission Index:EUROI
Net Weight (kg):810
Overall dimensions (length ×Width ×Height)(mm):1576×753×1002
alternator (optional):1000W/1500W/3000W/4200W
Model: WD615.67A
Application:For truck
series:WD615series
Type:in-line water cooling four strokes direct injection
Intake Mode:Turbocharging Intercooling
No. of Cylinder× Bore× Stroke(mm):6×126×130
Total Displacement(L):9.726
Rated Power/ Speed (kW/r/min):177/2400
N.m/r/min Peak Torque/Speed(N.m/r/min):1160/1300-1600
Torque Rise(%):29.7
Fuel Consumption at Rated Conditions(g/kW.h):220
Oil Consumption(%):≤0.4
Max. Rated Speed Without load(r/min/):2470+50
Stable Idle Speed(r/min/):600±50
Noise(A):≤112
Max. Smoke at Full load(Rb):≤3.5
Smoke at free accelerate(Rb):≤2.5
Emission Index:EUROI
Net Weight (kg):850
Overall dimensions (length ×Width ×Height)(mm):1525×660×960
Model: WD615.68A
Application:For coach
series:WD615series
Type:in-line water cooling four strokes direct injection in-line
Intake Mode:Turbocharging Intercooling
No. of Cylinder× Bore× Stroke(mm):6×126×130
Total Displacement(L):9.726
Rated Power/ Speed (kW/r/min):225/2400
Peak Torque/Speed(N.m/r/min):1250/1300-1500
Torque Rise(%):28
Fuel Consumption at Rated Conditions:220
Min. Fuel Consumption(g/kW.h):200
Oil Consumption(%):≤0.4
Max. Rated Speed Without load(r/min/):2640±50
Stable Idle Speed(r/min/):600±50
Noise(A):≤112
Max. Smoke at Full load(Rb):≤3.5
Smoke at free accelerate(Rb):≤2.5
Emission Index:EUROI
Net Weight (kg):850
Overall dimensions (length ×Width ×Height)(mm):1525×660×960
SHANGHAI STONE DIESEL ENGINE CO.,LTD WD615 series diesel engine is an important component of the state level introduction project in the Chinese mechanical industry –introduction of the Steyr technology. Under the contract of the technical introduction, the Steyr Company of Austria would provide HAEP simultaneously with the newest technology in the valid contract period of 15 years to make the product of HAEP follow closely the development steps of the European diesel engines and keep the product at the internationally advanced
| Model | Rated Power/ Speed (kW/r/min) | Peak Torque/Speed (N.m/r/min) | Emission Index |
| WD615.46 Engine for truck | 266/2200 | 1460/1400-1600 | EUROII |
| WD615.56 Engine for truck | 193/2200 | 1100/1100-1600 | EuroII |
| WD615.44 Engine for truck | 243/2200 | 1250/1100-1600 | EUROII |
| WD615.44 Engine for truck | 235/2200 | 1250/1100-1600 | EUROII |
| WD615.61A Engine for truck | 193/2200 | 1110/1300-1600 | EUROI |
| WD615.327 Engine for truck | 198/2200 | 1150/1100-1600 | EUROIII |
| WD615.340 Engine for truck | 294/2200 | 1600/1100-1600 | EUROIII |
| WD615.329 Engine for truck | 213/2200 | 1160/1100-1600 | EUROIII |
| WD615.334 Engine for truck | 247/2200 | 1350/1100-1600 | EUROIII |
| WD615.58 Engine for truck | 175/2200 | 1000/1300-1600 | EUROII |
| WD615.338 Engine for truck | 276/2200 | 1500/1100-1600 | EUROIII |
| WD615.61J Engine for truck | 177/2400 | 780/1500-1600 | EUROI |
| WD615.68A Engine for truck | 225/2200 | 1250/1300-1500 | EUROI |
| WD415.21 Engine for truck | 155/2200 | 820/1300-1600 | EUROII |
| WD415.24 Engine for truck | 177/2200 | 950/1300-1600 | EUROII |
| WD615.67A Engine for truck | 206/2200 | 1160/1300-1600 | EUROI |
| WD415.18 Engine for truck | 137/2200 | 710/1300-1600 | EUROII |
| WD415.23 Engine for truck | 166/2200 | 880/1300-1600 | EUROII |
| WD615.50 Engine for truck | 201/2200 | 1110/1100-1600 | EUROII |
| WD615.37 Engine for truck | 275/2200 | 1460/1100-1600 | EUROII |
Diesel engine for XCMG TRUCK CRANE QY8B.5
Diesel engine for XCMG TRUCK CRANE QY12B.5
Diesel engine for XCMG TRUCK CRANE QY16B.5
Diesel engine for XCMG TRUCK CRANE QY16C
Diesel engine for XCMG TRUCK CRANE QY16D
Diesel engine for XCMG TRUCK CRANE QY20B.5
Diesel engine for XCMG TRUCK CRANE QY20G.5
Diesel engine for XCMG TRUCK CRANE QY25B.5
Diesel engine for XCMG TRUCK CRANE QY25K-II
Diesel engine for XCMG TRUCK CRANE QY25K5-I
Diesel engine for XCMG TRUCK CRANE QY25E
Diesel engine for XCMG TRUCK CRANE XCT25E
Diesel engine for XCMG TRUCK CRANE XCT30E
Diesel engine for XCMG TRUCK CRANE QY35K5
Diesel engine for XCMG TRUCK CRANE QY30K5-I
Diesel engine for XCMG TRUCK CRANE QY40K
Diesel engine for XCMG TRUCK CRANE XCT50E
Diesel engine for XCMG TRUCK CRANE QY50B.5
Diesel engine for XCMG TRUCK CRANE QY50K-鈪?/span>
Diesel engine for XCMG TRUCK CRANE QY60k
Diesel engine for XCMG TRUCK CRANE XCT70E
Diesel engine for XCMG TRUCK CRANE QY70K-I(hydraulic control)
Diesel engine for XCMG TRUCK CRANE QY90K
Diesel engine for XCMG TRUCK CRANE QY100K-I(Weichai)
Diesel engine for XCMG TRUCK CRANE QY110K
Diesel engine for XCMG TRUCK CRANE QY130K
Diesel engine for XCMG TRUCK CRANE QY160K
