Manifold Absolute Pressure Sensor(MAP)

Product Attribute:

Voltage:5v

Pressure:300KPa

Applicationt:

auto

Production Description:

Model 612 incorporates MEMS technology and custom Application Specific Integrated Circuit (ASIC) technology in the design. It is specifically designed for tough automotive application.

Model 612 is designed to perform in the underhood harsh environment such as temperature extremes, vibration, thermal and mechanical shock, and corrosive chemical. Typical applications include manifold absolute pressure (MAP), barometric, ERG pressure and brake boost.


SENSOR SPECIFICATIONS

Electrical:

Supply Voltage5.0±0.1 V dc

Supply Current10 mA dc max

Maximum Output Current Sink 1 mA dc

Source 0.1 mA dc

Output Impedance <50 ohms

Output Voltage0.25 to 4.85 V dc

Sensor Operating Characteristics:

Range 0 to 15.2 psia;0 to 105 KPa; 0 to 1.05 bar

Proof Pressure300 KPa

Static Accuracy (%FS)11.5 typ.

Environmental Effects:

Compensated Temperature Range -40 to +150

Storage Temperature Range -50 to +165

Mechanical:

Media CompatibilityMedia Compatible with Silicon
