Product Attribute:
Applicationt:
-
Production Description:
Features
• IP65 , rugged aluminum case, fit in variety harsh environment
• Capable of temperature compensation. Linear adjustment temperature & humidity by computer, analog output or option RS-485
• Measure high accuracy Temp. & humidity, reaction quickly, the sensor can work well after temporary condensation, long term stable in high humidity environment
• Process Temp. : up to 200°C, S.S. probe proof pressure : 10 bar, metal connector : installation repeatedly
• Switch multifunction physical quantities[%RH][°C][mbar][g/kg][g/m3][kj/kg]
• Calibration physical quantities, measuring range, analog output, station, etc
• Free calibration software : data logger / record 65535 datas / charts
Applications
Semiconductor / Electronics / Industrial process monitoring / Air conditioning / Environmental ventilation control buildings / Factories / Hospitals / Clean rooms / Laboratories / Weather stations environmental monitoring / Storage rooms / Environmental chambers / Greenhouses / Mushroom farms / / Paper / Printing Textiles / Steel and iron industry / Food / Chemical / Pharmaceutical / Biotechnology industry
Specification
|
Input
|
|
Signal type
|
Capacitive humidity sensor & Pt 100 A class
|
|
Output
|
|
Output
|
0 ... 20 mA / 4 ... 20 mA
|
|
0 ... 1 V / 0 ... 5 V / 0 ... 10 V
|
|
Signal connection
|
3-wire
|
|
Modbus
|
2 analog / option RS-485 (Programmable)
|
|
Display type
|
LCD Module with back light, double line character
|
|
Display range
|
upon request, one decimal place
|
|
Height of character
|
5.55 mm
|
|
Accuracy ( at +25 )
|
|
Temperature
|
±0.15±0.002xtactual
|
|
Humidity ( 0 ... 90 %RH )
|
Nonlinear error±1.2%RH
|
|
Hysteresis error±0.8%RH
|
|
Repeatability error±0.4%RH
|
|
Humidity ( 90 ... 100 %RH)
|
±2%RH
|
|
Thermal sensitivity
|
|
Temp. error
|
0.05%RH/
|
|
Load resistance
|
Current output : Max. 500 Ω
|
|
Voltage output : min. 10 KΩ
|
|
Output calibration( ZERO & SPAN )
|
Software / Keybord
|
|
Response time t90 ( at 25 )
|
20 sec ( S.S.Metal grid filter with mesh )
|
|
30 sec ( Sintered filter )
|
|
Factory uncertainty ( at +25 )
|
|
Temp. uncertainty
|
0.14
|
|
Humidity uncertainty
|
0.4%RH (> 10 ... 20%)
|
|
0.65%RH (> 20 ... 90%)
|
|
0.97%RH (> 90 ... 98%)
|
|
Electrical
|
|
Power supply
|
DC 8 ... 35 V / AC 12 ... 30 V
|
|
Current consumption
|
DC 24 V60 mA / DC 12 V120 mA
|
|
AC 24 V140 mA / AC 12 V230 mA
|
|
Electrical connection
|
M12 metal connector with 2 m cable or terminal ( Metal cable gland )
|
|
Environmental
|
|
Medium
|
Air
|
|
Temp. Operating
|
Housing-20 ... +80
|
|
Housing with display-20 ... +60
|
|
Humid. Operating
|
Housing0 ... 95% (Non-condensing)
|
|
Probe operating
|
Wall type-40 ... +80
|
|
Duct type-40 ... +120
|
|
Remote type-40 ... +200
|
|
Storage temperature
|
-25 ... +60
|
|
Probe pressure resistance
|
10 bar
|
|
Material
|
|
Housing
|
Aluminum alloy
|
|
Probe
|
SUS 304
|
|
Cable
|
Teflon
|
|
Weight
|
THM801455 g
|
|
THM802521 g
|
|
THM803635 g
|
