SE 600 Conductivity Sensor 4-electrode sensor for high-pressure and high-temperature applications; large measuring range from pure water up to high conductivities For special chemistry applications up to 210 and 25 bar. Universal measuring range from pure water to 600 mS/cm. With fixed cable and integrated temperature detector. Process-wetted materials: stainless steel and PTFE; very compact design. SE 600 Conductivity Sensor Applications Special chemical processes; condenser monitoring, also for heavily polluted, e.g. fibrous media, pulp production. SE 600 Conductivity Sensor Facts - Large measuring range due to 4-electrode technology - Measurement at high temperatures and pressures - High level of process safety due to durable materials and robust design - Slim, ultracompact design (25 mm diameter) SE 600 Conductivity Sensor Specifications
Cell constant *)
0.14 cm ~ 0.38 cm (exact value printed on rating plate)
Measuring range
approx. 0.5S/cm ~ 600 mS/cm
Material
Body PTFE / stainless steel AISI 316 L
Electrodes
stainless steel AISI 316 L
Temperature detector
Pt 1000 (IEC Class A)
Temperature
max. 210
Pressure
max. 25 bar
Process connection
1" weld nipple (see Accessories)
Cable
Fixed cable, 5 m
