Dust Sensor

Product Attribute:

Applicationt:

-

Production Description:

Application
    This specification applies to the outline and characteristics of Model No. GP2Y1026AU0F (Dust sensor).

Electro-optical Characteristics
(Ta=25, Vcc=5V)

Parameter	Symbol	Conditions	Min.	Typ.	Max.	Unit
Sensitivity	K	(*1)(*2)	0.29	0.35	0.41	V / (0.1mg/)
Sensitivity Output at no dust	Vo	(*1)(*2)	0			V
Output terminal voltage	Txdl	Output voltage at High-level (Ioh=1.5mA)	4.35			V
	Txdl	Output voltage at Low-level (Ioh=1.5mA)			0.8	V
Average supply current	ICC	Vcc=5V		15	20	mA

(*1) Dust density shall be measured the density of MEVIUS (made by Japan Tobacco Inc.) by using a digital dust indicator P-5L2 (made by SIBATA SCIENTIFIC TECHNOLOGY LTD.).
 Sensitivity : K shall be specified about output change when dust density is changed 0.1mg/
(*2) Connection circuit example.
