MA40S4R Ultrasonic Sensors Specifications:
Operating Temperature Range
-40 to 85
Construction
Open type
Center Frequency
40kHz
Sensitivity
-63dB typ. (0dB=10V/Pa)
Directivity
80deg. (typ.)
Capacitance
2550pF
Capacitance Tolerance
±20%
MA40S4R Ultrasonic Sensors Features:
1. Compact and light weight.
2. High sensitivity and sound pressure.
MA40S4R Ultrasonic Sensors Applications:
Automotive Usage
Infotainment
Other Usage
1.Obstacle detection in home
2.Distance measurement
MA40S4R Ultrasonic Sensors Dimensions:
