Infrared Gas Analysis Module

Infrared Gas Analysis Module

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

RL-H150 Infrared Gas Analysis Module Applications:
    It is widely used in gas analysis in cement and metallurgical industry, greenhouse and scientific laboratory gas analysis in greenhouse, chemical fertilizer and chemical industry, gas analysis in industrial process, gas composition gas analysis in flue gas, environmental monitoring, medical monitoring, exhaust analysis, etc.

RL-H150 Infrared Gas Analysis Module Features:

  • Design of imported light source and dual-channel detector, built-in temperature compensation, with long life, high precision, fast response,good stability and so on
  • Small module, compact structure, easy to install
  • Advanced technology, high cost-performance

RL-H150 Infrared Gas Analysis Module Technical parameters:
Measurement principle: NDIR principle
Measurement components and ranges:
RL-H150 measurement components and ranges
Gas component model number measuring range remarks
CO2 RL-H150CO2 0~10%/30%/50%/100% Range optional
CO RL-H150CO 0~10%/30%/50%/100% Range optional
CH4 RL-H150CH4 0~10%/30%/50%/100% Range optional
C3H8 RL-H150C3H8 0~10%/30%/50%/100% Range optional
SF6 RL-H150SF6 0~10%/30%/50%/100% Range optional
NH3 RL-H150NH3 0~10%/30%/50%/100% Range optional
Resolution :0.01 per cent (based on range of measurements)
Linear errorFS;±2 per cent
Stabilityzero drift ±2% FS;
                 range drift ±2% FS;
Repeatability FS;±1 per cent;
Sample gas flow200~800 ml/ min;
Response timeT9010 seconds;
Working voltage6 VDC±5;
Drive current less than 140 MA;
Air intake modecontinuous air intake;
Sample gas temperature0~+50;
Working environment: temperature-10~+50
Humidity90 per cent;
Preheat time3 min;
Mode of communicationsensor with digital output Modbus ASCII 3.3VDC TTL, can achieve two-way communication with computer ;(external output board output 4-20 mA or RS485)
Shape sizeRL-H15062mm( length)×33 mm( width)
