1.General Description
The integrated circuit MS8883A is a capacitive switch that uses a patented (EDISEN) digital method to detect a change in capacitance on a remote sensing plate.
Changes in the static capacitance (as opposed to dynamic capacitance changes) are automatically compensated using continuous auto-calibration. Remote sensing plates (e.g. conductive foil) can be connected remotely to the IC using coaxial cable.
2.Applications
• Hermetically sealed keys on a keyboard
• Switch for medical applications
• Switch for use in explosive environments
• Vandal proof switches
• Automotive: Switches in or under upholstery, leather, handles, mats and glass
• Portable entertainment units
• Buildings: Switch in or under carpets, glass or tiles
• Sanitary applications: Use of standard metal sanitary parts (e.g. tap) as switch
3.Typical application
4.Features
• Dynamic proximity switch
• Digital processing method
• Automatic calibration
• Sensing plates can be connected remotely
• Open-drain output (P-type MOSFET, external load between pin and ground)
• Designed for battery powered applications (IHI typ. 3μA)
• Adjustable response time
• Adjustable sensitivity
• Output configurable as push-button, toggle or pulse
• Large voltage operating range (VHI = 3.0 to 9V)
• Large temperature operating range (Tamb = -40 to 85°C)
• Internal voltage regulator
• Available in SO8 package
