Heat Flux Sensor

Heat Flux Sensor

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

1.Heat Flux Sensor - gSKIN-XO Descriprion:
    Robust heat flux sensor to perform measures under harsh conditions.

2.Heat Flux Sensor - gSKIN-XO Features:

  • Ultra-high resolution of thermal energies and temperature differences
  • Robust sensor
  • Model with connectors compatible with all gSKIN(R) DLOG Data Loggers
  • Sensor with conductive heat flux calibration cohering to ISO 8301

3.Heat Flux Sensor - gSKIN-XO Applications:
    In-situ building monitoring, U-Value determination, environmental monitoring e.g. soil

4.Heat Flux Sensor - gSKIN-XO Technical parameters:
Product
gSKIN XO
Detector Type
Thermoelectric
Surface Material (Sensing Area)
Polyamide
Sensing Dimensions (mm)
30.0 x 30.0 x 3.3
Heat Flux Range Min / Max [kW/m²]
-15/ 15
Noise Equivalent Heat Flux per area [W/m²] / absolute [W]
0.073 / 65.7 (Experimentally evaluated values under optimal steady state conditions).
Heat Flux Resolution per area [W/m2] with gSKIN® DLOG / absolute [W]
0.09 / 81.0 (Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219).
Response Time (0-95%) [s]
n/a
Min. /Avg. Sensitivity (S) [V/(W/m²)]
10.0/20.0 (Only a reference point).
Max. Compressive Force when clamped [kgf]
>32 (not specified)
Electrical Resistance [Ohm]
<150
Thermal Conductivity [W/(m*K)]
0.4
Absolut Thermal Resistance [K/W]
2.8
Linearity with Power [±%]
1
Operating Temperature Range Min/Max [°C]
-50 / 80
Calibration Accuracy [±%]
3
Calibration Temperature Range Min/Max [°C]
-30 / 70 (Refers to the heat flux measurement).V
Temperature Dependence of S [%/°C]
0.25 (The sensitivity increases/decreases as the temperature goes above/below 22.5°C.
Homogeneity [±%]
1 (Position dependent signal change across sensing area).
Cable Length (c) [cm]
100
