1.Heat Flux Sensor - gSKIN-XM Descriprion:
Small heat flux sensor for performing reliable measurements under controlled conditions. Available both without and with connector.
2.Heat Flux Sensor - gSKIN-XM Features:
• Ultra-high resolution of thermal energies and temperature differences. • Low invasiveness and thickness. • Models with connector compatible with all gSKIN®DLOG Data Loggers. • All sensors with conductive heat flux calibration cohering to ISO 8301.
3.Heat Flux Sensor - gSKIN-XM Applications:
R&D, thermal optimization, energy efficiency, industrial monitoring of thermal properties.
4.Heat Flux Sensor - gSKIN-XM Technical parameters:
Product
gSKIN XM
Detector Type
Thermoelectric
Surface Material (Sensing Area)
Aluminum
Sensing Dimensions (mm)
4.4 x 4.4 x 0.5
Heat Flux Range Min / Max [kW/m²]
-150 / 150
Noise Equivalent Heat Flux per area [W/m²] / absolute [μW]
0.340 / 6.6 (Experimentally evaluated values under optimal steady state conditions).
Heat Flux Resolution per area [W/m2] with gSKIN® DLOG / absolute [μW]
0.41 / 7.9 (Guaranteed minimum heat flux resolution using the gSKIN® DLOG-4219)
Temperature Difference Resolution [μK]
∼140
Response Time (0-95%) [s]
0.7
Min. /Avg. Sensitivity (S) [μV/(W/m²)]
1.5 (Only a reference point).
Max. Compressive Force when clamped [kgf]
< 2
Electrical Resistance [Ohm]
< 20
Thermal Conductivity [W/(m*K)]
∼1.1
Linearity with Power [±%]
1
Operating Temperature Range Min/Max [°C]
-50 / 150
Calibration Accuracy [±%]
3
Calibration Temperature Range Min/Max [°C]
-30 / 70 (Conductive heat flux calibration cohering to the ISO8301 standard with mean temperature of 22.5°C).
Flexprint Length (f) [cm]
5
Temperature Dependence of S [%/°C]
0.25
Homogeneity [±%]
1 (The sensitivity increases or decreases as the temperature goes above or below 22.5°C). Position dependent signal change across sensing area.
Cable Length (c) [cm]
100
