UVC Photodiode

UVC Photodiode

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

1. UVC photodiodeGT-UVC-LProduct info
Solar-blind detector, chip size 1 mm2, TO46 metal package with sapphire window, high sensitivity and low leakage, spectral response range 220-290 nm.

2. UVC photodiodeGT-UVC-LTypical applications
UV sterilizing lamp monitoring, UV radiation dose measurement, flame detection

3. UVC photodiodeGT-UVC-LGeneral Features

  •  Selective response to UVC band
  •  Photovoltaic mode operation
  •  TO-46 metal housing
  •  Good solar blindness
  •  High responsivity and low dark current

4. UVC photodiodeGT-UVC-LSpecifications
Parameters Symbol Value Unit
Maximum ratings
Operation temperature range   Topt -25-85
Storage temperature range   Tsto -40-80
Soldering temperature (3 s) Tsol 260
Reverse voltage    Vr-max -10 V
General characteristics (25)
Chip size A 1 mm2
Dark current (Vr = -1 V)   Id <1 nA
Temperature coefficient   Tc -0.02 %/
Capacitance (at 0 V and 1 MHz) Cp 18 pF
Spectral response characteristics (25)
Wavelength of peak responsivisity   p 285 nm
Peak responsivisity (at 285 nm)    Rmax 0.178 A/W
Spectral response range (R=0.1×Rmax)   225-290 nm
UV-visible rejection ratio (Rmax/R400 nm)   >104

5. UVC photodiodeGT-UVC-LPackage dimensions

UVC Photodiode
