UV Photodiode

UV Photodiode

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

1.UV photodiodeGT-UVV-LWProduct info
Chip size 1 mm2, TO46 metal package with sapphire window, high sensitivity and low leakage, spectral response range 350-440 nm.

2.UV photodiodeGT-UVV-LWTypical applications
UV LED Monitoring, UV radiation dose measurement, UV Curing

3.UV photodiodeGT-UVV-LWGeneral Features

  •  Indium Gallium Nitride Based Material
  •  Photovoltaic mode operation
  •  TO-46 metal housing
  •  High responsivity and low dark current

4. UV photodiodeGT-UVV-LWSpecifications
Parameters Symbol Value Unit
Maximum ratings
Operation temperature range   Topt -25-85
Storage temperature range   Tsto -40-85
Soldering temperature (3 s) Tsol 260
Reverse voltage    Vr-max -10 V
General characteristics (25)
Chip size A 1 mm2
Dark current (Vr = -1 V)   Id <1 nA
Temperature coefficient   Tc  0.05 %/
Capacitance (at 0 V and 1 MHz) Cp 60 pF
Spectral response characteristics (25)
Wavelength of peak responsivisity   p 390 nm
Peak responsivisity (at 390 nm)    Rmax 0.289 A/W
Spectral response range (R=0.1×Rmax)   290-440 nm
UV-visible rejection ratio (Rmax/R400 nm)   >104

5.UV photodiodeGT-UVV-LW Package dimensions

UV Photodiode
