UV Photodiode

UV Photodiode

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

1. UV photodiodeGS-ABC-3535LQCProduct info
Chip size 1 mm2, SMD3535 package with quartz window, high sensitivity and low leakage, spectral response range 210-370 nm.

2. UV photodiodeGS-ABC-3535LQCTypical applications
air purification, water quality measurement

3. UV photodiodeGS-ABC-3535LQCGeneral Features

  •  UVA+UVB+UVC photodiode
  •  Photovoltaic mode operation
  •  SMD 3535 ceramic package with quartz window
  •  Good visible blindness
  •  High responsivity and low dark current

4. UV photodiodeGS-ABC-3535LQCSpecifications
Parameters Symbol Value Unit
Maximum ratings
Operation temperature range   Topt -25-85
Storage temperature range   Tsto -40-85
Soldering temperature (3 s) Tsol 260
Reverse voltage    Vr-max -10 V
General characteristics (25)
Chip size A 1 mm2
Dark current (Vr = -1 V)   Id <1 nA
Temperature coefficient   Tc -0.02 %/
Capacitance (at 0 V and 1 MHz) Cp 18 pF
Spectral response characteristics (25)
Wavelength of peak responsivisity   p 355 nm
Peak responsivisity (at 355 nm)    Rmax 0.2 A/W
Spectral response range (R=0.1×Rmax)   210-370 nm
UV-visible rejection ratio (Rmax/R400 nm)   >104

5. UV photodiodeGS-ABC-3535LQCPackage dimensions


UV Photodiode
