High Concentration Carbon Monoxide Sensor CO Sensor

High Concentration Carbon Monoxide Sensor CO Sensor

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

CO-AE Carbon Monoxide Sensor CO Sensor Description
Alphasense Carbon Monoxide gas sensors operate using proven fuel cell technology.

CO-AE Carbon Monoxide Sensor sizes:
20mm diameter, the industry standard size for portable gas detectors

The Alphasense family of CO sensors have proven themselves in the field with long term stability and reliable operation, well beyond the two-year warranty, using our patented electrode technology.


CO-AE Carbon Monoxide Sensor CO Sensor PERFORMANCE
Sensitivity nA/ppm in 2,000ppm CO 10 to 25
Response time t90 (s) from zero to 2,000ppm CO < 50
Zero current ppm equivalent in zero air < ± 20
Resolution RMS noise (ppm equivalent) < 5
Range ppm CO limit of performance warranty 10,000
Linearity ppm error at full scale, linear at zero and 2000ppm CO < 0 to 500
Overgas limit  maximum ppm for stable response to gas pulse 100,000

CO-AE Carbon Monoxide Sensor CO Sensor LIFETIME
Zero drift ppm equivalent change/year in lab air < 2
Sensitivity drift % change/year in lab air, monthly test < 1
Operating life months until 80% original signal (24 month warranted) > 24

CO-AE Carbon Monoxide Sensor CO Sensor ENVIRONMENTAL
Sensitivity @ -20°C % (output @ -20°C/output @ 20°C) @ 400ppm CO 65 to 93
Sensitivity @ 50°C % (output @ 50°C/output @ 20°C) @ 400ppm CO 98 to 115
Zero @ -20°C ppm equivalent change from 20°C < ±2
Zero @ 50°C ppm equivalent change from 20°C < ±5

CO-AE Carbon Monoxide Sensor CO Sensor CROSS SENSITIVITY
Filter capacity ppm-hours H2S 3,000,000
Filter capacity ppm-hours NO2 8,000,000
Filter capacity ppm-hours NO 200,000
Filter capacity ppm-hours SO2 4,000,000
H2S  sensitivity % measured gas @ 20ppm H2S < 0.1
NO2  sensitivity % measured gas @ 10ppm NO2 < 0.1
Cl2    sensitivity % measured gas @ 10ppm Cl2 < 0.2
NO    sensitivity % measured gas @ 50ppm NO < 0.1
SO2   sensitivity % measured gas @ 20ppm SO2 < 0.1
H2     sensitivity % measured gas @ 400ppm H2 at 20°C < 75
C2H4 sensitivity % measured gas @ 400ppm C2H4 < 60
NH3   sensitivity % measured gas @ 20ppm NH3 < 0.1

CO-AE Carbon Monoxide Sensor CO Sensor KEY SPECIFICATIONS
Temperature range °C -30 to 50
Pressure range kPa  80 to 120
Humidity range % rh continuous 15 to 90
Storage period months @ 3 to 20°C (stored in sealed pot) 6
Load resistor (recommended) 10 to 47
Weight g < 6

Matched Transmitter board for CO-AE CO Sensor

4-20 mA Digital Transmitter Board
    Factory calibration, custom-set for immediate use
    Digital zero, sensitivity and temperature compensation
    Digital and 4-20mA output
    Biased or unbiased operation
    Calibration and range change

High Concentration Carbon Monoxide Sensor CO Sensor
