Dual Beam NDIR CO2 Sensor Module

Dual Beam NDIR CO2 Sensor Module

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

ZG Module - ZG01C

  • Use Dual Beam NDIR technology to improve the long term stability
  • Cost - effective CO2 monitors made with IR-SOC technology
  • Small Module for OEM


ZG01C NDIR CO2 Sensor Module Application:

  • IAQ (Indoor air quality)
  • Greenhouse
  • HVAC.DCV (Demand Control Ventilation)


ZG01C NDIR CO2 Sensor Module Specifications



Method - Dual Beam NDIR
Sample Method Diffusion or flow through (50~200ml/min)
Operating Conditions 0~50°C (32~122° F) 0-95% RH, non-condensing
Storage conditions -20~60°C (-4~140°F), 95%RH
Temperature Typ.±0.2% of reading per °C or ±2 ppm per °C, whichever is greater,
Dependence referenced to 25°C
Performance - CO2 Channel
Measurement Range 0~3,000ppm/ 0.3% (ZG01C) or 0~10,000ppm/ 1.0% (ZG01C-M)
Accuracy ±50ppm or 5% of reading
Repeatibility ±20ppm
Temperature Dependence Typ.±0.2% of reading per °C or ±2 ppm per °C, whichever is greater, referenced to 25°C
Pressure Dependence 0.13% of reading per mm Hg
Response Time About 2 min
Resolution 1ppm
Warm Up Time <60 sec
Performance - Temperature Channel
Temperature Range 0~50°C (32~122° F)
Accuracy ±1°C(±2°F) When the fan blows to the device directly, the accuracy of temperature is ±1.5 °C.
Response Time 20-30 minutes (case must equilibrate with environment)
Power Supply and Output
Power Supply 5VDC supply (±5%),Ripple and Noise (mVp-p) 200
Power Consumption Max.200mA, average :20mA
Output Interface 6pin Vertical Connector, Space=2.0mm &FFC (Flat Flexible Cable) connector
Digital Output UART (Baud Rate: 19200, Check Bit: None, Data Bit: 8 bit, Stop Bit: 1)

Dual Beam NDIR CO2 Sensor Module
