SOL-PYR Solar Radiation Pyranometer Description The Pyranometer is designed for measurements in solar, agricultural, meteorological and hydrological studies. The sensor features a PIN silicon photo diode mounted in a fully cosine- corrected miniature head. Output of the sensor is a voltage equal to 0.5 millivolts per watt per square meter for sunlight intensities of up to 2000 watts per square meter. The standard resolution of the sensor is 10 watts per square meter. Using a 10 bit digitizer, the sensor is capable of providing minimum resolution of 2 watts per square meter. The Pyranometer is available with either a flat base or plug-in mount to fit the RainWise Monopod mounting system. It is manufactured of high stability silicon (detector), aluminum, stainless steel and PVC. When installed in a RainWise Monopod the sensor utilizes the mounts built-in level When purchased as a separate sensor, a level is attached to the sen- sor housing. The Pyranometer is covered by a five year warranty. SOL-PYR Solar Radiation Pyranometer Specifications
