Digital Two-Wire Loop Powered Infrared Temperature Sensor

Digital Two-Wire Loop Powered Infrared Temperature Sensor

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

PSC-CX
Digital, two wire, loop powered infrared temperature sensor for OEM applications

PSC-CX Infrared Temperature Sensor Description
The PSC-CS self-Contained, 2-wire loop powered IR temperature sensor with 4-20 mA output features:
High-performance, great value
Simple 2-wire installation
Wide range of -30°C to 900°C (adjustable with PSC Connect Software)
Optical resolution of 22:1
Optional USB programming interface
Alarm output (0-30 V / 500 mA)
Real-time 2-wire output and digital communication
Versatile power requirements: 5-30 VDC

PSC-CX Infrared Temperature Sensor Specifications

General Specifications
Environmental rating IP 65 (NEMA-4)
Ambient temperature -20 - 75°C
Storage temperature sensing head: -40 - 85°C
Relative humidity 10-95%, non condensing
Vibration IEC 68-2-6: 3 G, 11-200 Hz, any axis
Shock IEC 68-2-27: 50 G, 11ms, any axis
Weight 350 g
Electrical Specifications
Outputs/analog 4 - 20 mA
Output/Alarm 0-30 V/ 500 mA (open collector)
Outputs/digital (optional) USB
Loop impedances max. 1000
Cable length 8 m
Power supply 5 - 30 V DC
Measurement Specifications
Temperature range (scalable via software) -30 - 900°C
Spectral range 8 -14µm
Optical resolution 22:1
CF-Optics (optional) 0.6mm @10 mm
System accuracy (at ambient temperature
23±5°C and object temperture >20°C)		 ±1% or ±1.4°C
Repeatability (at ambient temperature
23 ±5°C and object temperture >20°C)		 ±0.5% or ±0.7°C
Temperature resolution 0.1°C
Exposure time (90% signal) 150ms
Emissivity/Amplification (adjustable via soft-ware) 0.100 - 1.100
Transmissivity (adjustable via software) 0.100 - 1.000
Signal processing (parameter adjustable
only via softwre)		 peak hold, valley hold, average; extended hold
function with threshold and hysteresis

Digital Two-Wire Loop Powered Infrared Temperature Sensor
