Self Contained Analog Ultrasonic Proximity Sensor

Self Contained Analog Ultrasonic Proximity Sensor

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

RPS-150A Ultrasonic Proximity Sensor Features

  •  Adjustable Zero & Span
  •  Broad Sensing Beam
  •  Range 2 to 40 or 5 to 80
  •  LED Strength Indicator
  •  Analog Current & Voltage Outputs
  •  Selectable Inverted & Non-Inverted Outputs
  •  Short Circuit & Reverse Polarity Protected
  •  Limit Switch Style Housing

RPS-150A Ultrasonic Proximity Sensor Description
The RPS-150A analog ultrasonic sensor is mounted in a limit switch style housing and is completely self contained. It is powered by 20-30VDC, and is reverse polarity protected. It also has a wide beam angle which enables it to detect a target that is not at right angles. A flat target can tilt up to 35 degrees and still be detected. The RPS-150A has 2 short circuit protected analog outputs, 4-20mA and 0-10VDC. These outputs can easily be inverted and can be scaled over almost any range by means of adjusting the zero & span control. For set-up purposes an LED signal strength indicator is provided. The RPS-150A ultrasonic sensors can be used as level control devices for liquid level and bulk materials.

This LED is green when not detecting and fades to RED as a target moves into place, depending on how much reflected signal is coming back from the target. The frequency of operation is 38.5kHz. There are two ranges available in this model 2 to 40 or 5 to 80. It also features a quick disconnect (QD) receptacle. The housing is constructed of PBT plastic and has standard 30mm x 60mm limit switch mounting dimensions as well as side holes for mounting the sensor on its side.

RPS-150A Ultrasonic Proximity Sensor Specifications



Operational Range: Adjustable 2 - 40"
Adjustable 5 - 80"
Power Input: 20 - 30VDC Reverse Polarity Protected
Input Current: 50mADC
Ambient Temperature: 0 - 60ºC or 32 - 140ºF
Humidity: 0 - 95% Non-Condensing
Housing: PBT Plastic, Limit Switch Style
Outputs: Current Sourcing Analog Output
4 - 20mA Inverted & Non-Inverted
Load 0 Ohms to 500 Ohms
Analog Voltage Output
0 - 10V Inverted & Non-Inverted
Load 500 Ohms to infinity
Short Circuit Protected
Transducer Frequency: 38.5kHz
Response Time:
  2 - 40"
  5" - 80"
22ms
52ms
Weight: 9.5 ounces







PART NUMBER RANGE OUTPUT / DESCRIPTION
RPS-150A-40
RPS-150A-80		 2 - 40" 5 - 80" 0 - 10VDC and 4 - 20mA Analog - Cable Sold Separately
0 - 10VDC and 4 - 20mA Analog - Cable Sold Separately
F32-5001183
F32-5001186		   2 meter QD Cable, M12 4-Pin 22AWG
5 meter QD Cable, M12 4-Pin 22AWG
