Controller With Remote Sensing Head

Controller With Remote Sensing Head

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

RPS-100 Controller With Remote Sensing Head Features

  • Various Sensing Ranges

  • Broad Sensing Beam

  • Low Frequency - 38.5kHz

  • LED Indicator

  • Small Transducer Head

  • Remote Transducer

  • RPS-500 Compatible

  • 3 - Way Power Operation

  • Isolated Form C Relay Output

  • Small Electronic Controller

RPS-100 Controller With Remote Sensing Head Description
The RPS-100 is the first of the RPS series and has a proven track record of reliability. Since its introduction in 1979, the RPS-100 has proven itself in versatility and ease of operation. The remote transducer allows for mounting of the sensor head in cramped spaces while the controller is out of the way. The ranging and proximity modes provide the versatility of simple detection, or actual distance measuring.

The isolated form C relay furnishes N.O. and N.C. outputs, and with the addition of the RPS-500 card various analog outputs are supplied. The RPS-100 sensor, which operates at a frequency of 38.5kHz, has a broad sensing beam which allows for detection of an object at greater angles of tilt. Sensing ranges available for the RPS-100 include 2 to 14, 5 to 72, and 10 to 240. Mounting flanges, LED indicator, ranging potentiometer, and 6-ft. transducer cable are included. Optional cable lengths are available.

RPS-100 Controller With Remote Sensing Head Specifications




Operational Range: Adjustable 2" to 14"
Adjustable 5" to 72"
Adjustable 10" to 240"
Power Input:
   *Only 120VAC or 24VDC
    with 500 Analog card. 		 120VAC
15 - 24VDC
12VDC Regulated
12 - 17VAC
Input Current: 30 Milliamps
Input Current with 500 card: 50 Milliamps
Ambient Temperature: 0C to 60C or 32F to 140F
Controller: Metal Enclosed
Transducer: Aluminum
Transducer Housing: Plastic
Output: N.O., N.C.  Isolated Form C Relay
.5 Amp Maximum at 120VAC
12VDC Logic Signal
Output with 500 card:  0 - 10VDC, 4 - 20 mA Analog Outputs with
Zero, Span, Sample, and Hold controls.
Transducer Frequency: 38.5kHz
Response Time:
  2" to 14"
  5" to 72"
  10" to 240"
30mS - On; 30mS - Off
100mS - On; 100mS - Off
250mS - On; 250mS - Off
Weight of Transducer: 2.2 ounces
Weight of Controller: 34.2 ounces



PART NUMBER RANGE OUTPUT
RPS-100-14
RPS-100-72
RPS-100-240		 2" - 14" 5" - 72" 10" - 240" Isolated form C Relay
Isolated form C Relay
Isolated form C Relay
RPS-100-14-500
RPS-100-72-500
RPS-100-240-500		 2" - 14"
5" - 72"
10" - 240"		 0 - 10VDC and 4 - 20mA Analog
0 - 10VDC and 4 - 20mA Analog
0 - 10VDC and 4 - 20mA Analog

Controller With Remote Sensing Head
