Vortex II Series Heavy Duty Anemometer This new (November 2013) heavy duty anemometer has a longer shaft than the original Vortex (for reduced vibration), and includes options for Reed or Hall Sensor, Tubular Mount, or Metal Cups. Ideally suited for applications to measure wind speed in all conditions.
Vortex II Series Heavy Duty Anemometer Specification
SENSOR TYPE
3-Cup Lexan rotor (Metal option) Internal sensor is a dry contact reed switch (standard), Hall Sensor (optional). The Hall Sensor requires 5VDC input
SENSOR RANGE
125+ MPH
DISPLAY
Optional Display Kit - directly compatible with the reed switch option (not the Hall Sensor Option)
MOUNTING
Flat metal bracket: 2 holes provided Tubular mounting option: 2 holes provided
ACCURACY
+/-4% of reading or 1 mph, whichever is greater (depends on the display used)
ROTOR DIAMETER
approx. 6 in (152 mm)
LENGTH
approx. 11 in (280 mm) overall with the flat metal bracket approx. 16 in with the optional tubular mount.
WIDTH
The Vortex II Series Anemometer includes the following:
The Vortex series of wind sensors have a reputation for being well made, accurate, reliable, and affordable. This latest version includes enhancements that our customers have been asking for over the years. Here is what the tubular mount option and the metal cups options look like:
