Multi-Purpose Photoelectric Sensor

Multi-Purpose Photoelectric Sensor

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

RP74 Series Multi-purpose Photoelectric Sensor Description
Built-in Timer Modes
Several Mounting Options
Universal Power Supply
Long Range




Modes Ranges
Through Beam 61m
Retroreflective 9.14m
Diffuse 3.04m
Clear Object Detection 1.2m
Fiber Optic Mode - (range depends on fiber used)




RP74 Series Multi-purpose Photoelectric Sensor



  Through-beam Diffuse Retroreflective (Polarized) Fiber Optic Clear Object Detection
Operating Range 61m (200 ft.) 3.04m (10 ft.) 9.14m (30 ft.) Depends on fiber 1.20m (3.9 ft.)
Light Emission 880nm Infrared LED 880nm Red LED 660nm Red LED 880nm Infrared LED 660nm Red LED
DC Models (10-40 VDC) M12 - Recommended Mating Cable: part # R-FS4TZ-V075 (straight), R-FA4TZ-V075 (right-angle)
Emitter RP74-T061MD-EY9Q4LE
NPN / PNP -
with timing		 RP74-T061MD- CY9Q4UE-T RP74-D3040D- CY9Q4UE-T RP74-L9140D-
CY6Q4UE-T		 RP74-FGFD-
CY9Q4UE-T		 RP74-S1200D-
CY6Q4UE-T
AC Models (12-240 VDC/24-240 VAC) ½"-20 UNF - Recommended Mating Cable: part # U-FS5TA-V105 (straight), U-FA5TA-V105 (right-angle)
Emitte RP74-T061MA-EY9Q4LM
SPDT Relay RP74-T061MR-
CY9Q5LM-T		 RP74-D3040R-
CY9Q5LM-T		 RP74-L9140R- CY6Q5LM-T RP74-FGFR-
CY9Q5LM-T		 RP74-S1200R-
CY6Q5LM-T
Technical Data
Power Supply 10-40 VDC or 12-240VDC/24-240 VAC
Indicator LEDs Green: Power, Yellow: Output, Red: Margin
Current Consumption 30mA max.
Saturation Voltage 2.5 V max.
Output Current 30mA max.
Response Time NPN/PNP: 5ms, SPDT Relay: 23ms
Timing Options No Delay, On Delay, Off Delay, One-shot (for Models With Timing Delay).
Time Settings Adjustable, 0.1...15s (for Models with Timing Delay)
Mechanical Protection IP67
Housing Material Glass Fiber Reinforced Plastic, Cover Gasket Material: Neoprene
Lens Materia Acrylic
Operating Temp. 25...+55°C (-13...+131°F)
Storage Temp. -40...+55°C (-40...+131°F)
Reference Standard EN 60947-5-2




Multi-Purpose Photoelectric Sensor
