Miniature Photoelectric Sensor

Miniature Photoelectric Sensor

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

RP32 Series Miniature Photoelectric Sensor Description
Compact & Rugged Design
Stainless Steel and Glass Fiber Reinforced Plastic Housing
Shock & Vibration Resistant




Modes Ranges
Through Beam 8.5m
Retroreflective 4m
Diffuse 400mm
Clear Object Detection 500mm

RP32 Series Miniature Photoelectric Sensor





  Through-beam Diffuse Retroreflective Clear Object Detection
Part Numbers
Emitter RP32-T8500D-
EY6Q4LP
NPN RP32-T8500N-
CY6Q4UP		 RP43-D0400N-
CY6Q4UP		 RP32-L4000N-
CY6Q4UP-PF		 RP32-L0500N-
CY6Q4UP-PD
PNP RP32-T8500P-
CY6Q4UP		 RP43-D0400P-
CY6Q4UP		 RP32-L4000P-
CY6Q4UP-PF		 RP32-L0500P-
CY6Q4UP-PD
Technical Data
Operating Range 8.5m (27.8 ft.) 400mm (15.7 in.) 4m (13 ft.) 0.5m (19 in.)
Power Supply 10 - 30 VDC
Current Consumption 35mA max.
Ripple ±10% (within Vs tolerance)
Light Emission 660nm Infrared LED
Angle of Divergence approx. 3.5° approx. 5.0° approx. 4.5°
Light Spot Size approx. 440mm@7m 40mm@400mm approx. 200mm@2.5m
Setting sensitivity trimmer
Output Voltage High: PNP: Vs - (1.5V); NPN is approx. Vs; Low: PNP is approx. 0V; NPN is 1.5V
Output Current Max. 100mA max., short-circuit protected and over current protected, Vs reverse polarity protected
Response Time <15 ms <2 ms <0.7 ms
Switching Frequency 33 Hz 250 Hz 700 Hz
Connection M8 4 pin connector - Recommended Mating Cable: Part # C-FS4TZ-V075 (straight),
or C-FA4TZ-V075 (right-angle)
Mechanical Protection IP67 / NEMA 6
Housing Material Stainless Steel / Glass fiber reinforced plastic
Operating Temp. -25 ~ +55°C (-13 ~ +131°F)
Storage Temp. -40 ~ +70°C (-40 ~ +158°F)
Reference Standard EN 60947-5-2




Miniature Photoelectric Sensor
