Rugged Oxygen Reduction Potential (ORP) Sensor

Rugged Oxygen Reduction Potential (ORP) Sensor

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

WQ600 ORP Sensor Description
WQ600 (Redox) ORP Sensor is a rugged and reliable ORP/Redox measuring device. The sensor is molded to 25' of marine grade cable, with lengths up to 500' available upon request. The WQ600's output is 4-20 mA with a three wire configuration. The unit's electronics are completely encapsulated in marine grade epoxy within a stainless steel housing.

WQ600 ORP Sensor Features

  • Continuous ORP monitoring
  • Fully encapsulated electronics
  • 4-20 mA output
  • Marine grade cable with strain relief
  • Stainless steel housing

WQ600 ORP Sensor Applications
Ideal for stream and lake monitoring, aquaculture studies, baseline analyses, mitigation monitoring, and other environmental applications.

WQ600 ORP Sensor Specifications
Output 4-20 mA
Range -500 to +500 mV
Accuracy 2% full scale
Maximum Pressure 40 psi
Operating Voltage 10 to 36 VDC
Current Draw 0.2 mA plus sensor output
Warm-up Time 3 seconds minimum
Operating Temperature -40° to +55°C
Cable Length 25' (up to 500' from factory)
Size of Probe Open Water: 1" dia. x 10½" long (2.5cm dia. x 26.7cm long)
Online: 2.5" dia. x 15.5" long (6.3cm dia. x 39.4cm)
Weight Open Water: 8 oz (227 g)
Online: 22 oz (623 g)

WQ600 ORP Sensor Ordering & Options
Order No. Description
WQ600 ORP Sensor for Open Water (includes 25' cable)
WQ600-O Online ORP Sensor (with 1-1/4" NPT thread and 25' cable)
WQEXC Extra Sensor Cable, per foot (up to 500')
