Highly Accurate And Stable Optical Dissolved Oxygen Sensor

Highly Accurate And Stable Optical Dissolved Oxygen Sensor

Application:  \

Market Type:  After Market

Product Attribute:

Applicationt:

\

Production Description:

WQ-FDO Optical Dissolved Oxygen Sensor Description
The WQ-FDO Optical Dissolved Oxygen Transmitter is an instrument designed for measuring dissolved oxygen concentrations in liquids.  The WQ-FDO Optical Dissolved Oxygen Transmitters were developed to meet different requirements ranging from surface water monitoring programs to harsh waste water applications.  The optical dissolved oxygen transmitter has been specifically designed to meet the demanding requirements of the environmental monitoring and scientific research sectors, providing long term, accurate and reliable dissolved oxygen measurement.  The WQ-FDO Optical Dissolved Oxygen Transmitter has extremely low power requirements and a 4-20 mA output making it ideal for incorporation into remote environmental monitoring installations.

WQ-FDO Optical Dissolved Oxygen Sensor Features

  • Extremely fast and precise optical DO sensor - outstanding for field and lab applications
  • Proven green light technology for long operation life of sensor
  • Beveled membrane repells interference that can be caused by air bubbles
  • Universal protective armoring available
  • Low power consumption and low maintenance
  • Simple to integrate and operate
  • One year sensor life

WQ-FDO Optical Dissolved Oxygen Sensor Applications
Long and short term monitoring for streams, rivers, lakes, aquaculture, thermocline profiling, industrial outfalls, wastewater, scientific research, homeland security, the food and wine industry, and more.

WQ-FDO Optical Dissolved Oxygen Sensor Specifications
Dissolved Oxygen
  Partial pressure: 0-400 mbar
  Accuracy: ± 0.5 % of value
  Repeatability: 0.01 ppm
  Response time: 90% in less than 60 seconds
  Sensor Drift: Less than 1% per year
  Temperature: Compensated 32 to 122°F (0 to 50°C)
Temperature
  Accuracy: ±0.2°F (±0.1°C)
  Resolution: 0.02°F (0.01°C)
  Range: 32 to 122°F (0 to 50°C
Max Pressure 35 psi (25m/82ft water depth)
Output Dual 4-20 mA (Partial Pressure and Temperature)
Operating Voltage 10-30 VDC
Current Draw 24 mA plus both sensor outputs
Warm Up Time 6 sec. min, 8 recommended
Operating Temperature 32 to +122°F (0 to +50°C)
Sensor Construction Acetyl, stainless steel, cast epoxy
Dimensions 0.86 inch dia. x 8 inch long (22mm dia. x 202mm long)
Weight 8 oz (227 g)

WQ-FDO Optical Dissolved Oxygen Sensor Ordering & Options
WQ-FDO Sensors
Order No. Output Type
WQ-FDO  Includes 25 ft of cable. Does not include armoring.
WQ SC-FDO Replaceable Membrane
WQEXC Extra Sensor Cable, per foot (up to 500 ft)

Accessories
Order No. Description
DD0505 Plastic Armor Housing, 1.89 inch (48 mm) dia.
DD0510 Stainless Steel Armor Housing, 1.89 inch (48 mm) dia.
