NDIR Carbon Dioxide (CO2) Sensor Module

NDIR Carbon Dioxide (CO2) Sensor Module

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

SH-300-NDTH NDIR Carbon Dioxide Sensor Module Features
Best Extremely Precise Sensor
Quick Response Time
Long Time Use, Stable performance at High & Low Temperature
Waterproof Filter for anti static filters fine dust and humidity in the air
One-way air indraft for represent average value when momentary CO2 Value change in the air
Low Current consumption
Output support: UART, 0~3V Analog

SH-300-NDTH NDIR Carbon Dioxide Sensor Module Application
CO2 Control for IAQ
Building, Hospital, School
Air cleaner, Air conditioner
Mushroom control, Boiler control

SH-300-NDTH NDIR Carbon Dioxide Sensor Module Technical Specification
CO2 Sensor

Measuring Type  Non-Dispersive Infrared (NDIR)
Measuring Range  0 ~ 3,000 / 5,000 / 10,000 ppm
Accuracy  FS ±2%, measured value±3% @ 0 ~ 50°C
Response Time  Every 2.0 Seconds
Warm-Up Time @25°C  < 90sec
Operating Condition  0 ~ 50°C, 0 ~ 95%RH (Non Condensing)
Output  Analog : 0~3VDC (0~3000, 5000, 10000ppm) [CN2]
 UART: 9600bps [CN1] / TTL Level 3.3V
Power Input  DC7V ~ 12V Input
 Fixed(Other Made): 5 VDC Regulated (±4%)
Consumption Current  Normal 38mA, Peak point 80mA
Interface  4PIN Header[CN2], 6PIN Header[CN1]
 Molex 5267 included.
 With 2.54mm spacing
Size  (W)65 mm x (H)45 mm x (D)17.6 mm (±0.5 mm)
Weight  22 g


Temperature Sensor

Range  -25 ~ 80°C
Accuracy  ±0.3°C
Response Time  5 ~ 30 Sec

Humidity sensor

Range		  0 ~ 100 %RH
Accuracy  ±2 %RH  Max. ±3 %RH
Response Time  8 Sec

NDIR Carbon Dioxide (CO2) Sensor Module
