NDIR Carbon Dioxide (CO2) Sensor Module (Dual Wavelength)

NDIR Carbon Dioxide (CO2) Sensor Module (Dual Wavelength)

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

SH-300-NDC NDIR CO2 Sensor Module Features
Best Extremely Precise Sensor
Quick Response Time
Long Time Use, Stable performance at High & Low Temperature
Waterproof Filter for anti static filters fine dust and humidity in the air
One-way air indraft for represent average value when momentary CO2 Value change in the air
Low Current consumption
Output support: UART, 0~3V Analog

SH-300-NDC NDIR CO2 Sensor Module Application
CO2 Control for Indoor Air Quality
CO2 Measuring for Ventilation Control
CO2 Control for Building, Hospital, School
CO2 Control for Air cleaner, Air conditioner.
Mushroom Control, Boiler Control

SH-300-NDC NDIR CO2 Sensor Module Technical Specification


Measuring Type
 Dual Light Wavelength Non-Dispersive Infrared (NDIR)
Measuring Range  0 ~ 3,000 / 5,000 / 10,000 ppm
Accuracy  ±2% FS, ±3 % measured value @0 ~ 50°C
Response Time  Every 2.0 Seconds
Warm-Up Time @25°C  < 90sec
Operating Condition  -10 ~ 50°C, 0 ~ 99.5% RH (Non-Condensing)
Output  Analog : 0~3VDC (0~3000, 5000, 10000ppm) [CN2]
 UART: 9600bps [CN1] / TTL Level 3.3V
Power Input  DC 7V ~ 12V Input
 Fixed(Other Made): 5 VDC Regulated (±4%)
Consumption Current  Normal 35mA, Peak 80mA
Interface  4PIN Header[CN2], 6PIN Header[CN1]
 Molex 5267 included.
 With 2.54mm spacing
Size  (W)65 mm x (H)45 mm x (D)17.6 mm (±0.5 mm)
Weight  19 g
