Dual Light Wavelength NDIR Carbon Dioxide (CO2) Sensor Module

Dual Light Wavelength NDIR Carbon Dioxide (CO2) Sensor Module

Application:  -

Market Type:  After Market

Product Attribute:

Applicationt:

-

Production Description:

SH-300-DS NDIR Carbon Dioxide Sensor Module Features
Best Extremely Precise Sensor
Quick Response Time
Long Time Use, Stable performance at High & Low Temperature
Waterproof Filter for anti static filters fine dust and humidity in the air
One-way air indraft for represent average value when momentary CO2 Value change in the air
Low Current consumption
Output support: UART, 0~3V Analog

SH-300-DS NDIR Carbon Dioxide Sensor Module Application
CO2 Control for Indoor Air Quality
CO2 Measuring for Ventilation Control
CO2 Control for Building, Hospital, School
CO2 Control for Air cleaner, Air conditioner.
Mushroom Control, Boiler Control

SH-300-DS NDIR Carbon Dioxide Sensor ModuleTechnical Specification




Measuring Type  Dual Light Wavelength Non-Dispersive Infrared (NDIR)
Measuring Range  0 ~ 3,000 / 5,000 / 50,000 / 100,000 ppm
Accuracy  ±2% FS, ±3% measured value @ 0 ~ 50°C
Response Time  Every 2.0 Seconds
Warm-Up Time @25°C  < 90sec
Operating Condition  -10 ~ 50°C, 0 ~ 99.5% RH (Non Condensing)
Output  Analog : 0~3VDC (0~3000, 5000, 10,000 ppm)
 UART: 9600bps [CN1] / TTL Level 3.3V
Power Input  DC 5V ~ 9V Input (5 ~ 7V recommendation)
Consumption Current  Normal 35mA, Peak 80mA
Interface  4PIN Header[CN1]
 Molex 5267 With 2.54mm spacing.
Size  (W)40mm x (H)36mm x (D)11.9 mm
Weight  12g
