CV7-E Ultrasonic Wind Speed Sensor Description
CV7-E Ultrasonic Wind Speed Sensor Specification:
Output data format
NMEA0183, MWV, XDR
Information transmited
Instant. W. Speed, Instant. W. Angle, avaibility
Output rate
4 Hz / 60 Hz measurement
Wind module sensitivity
0.12 m/s
Wind module resolution
0.05 m/s
Wind module dynamic
0.12 to 40 m/s
Direction sensitivity
+/-1.5°
Direction resolution
1°
Power supply
8 V to 30 V DC
Electrical consumption
9 mA
Op. temp. without icing
-15° C to +50° C
Cable
25 cm / 4x0.22 mm2, 20 g/m
Connection
4 wires
Weight of the head
100 gr
Weight of unit assembly
200 gr with mounting part
Mounting
Vertical, 300 carbon arm, Ø 16 mm
Options These industrial option are "Din" boxes with: 1x connection for 24VDC/AC power supply 1x connection for CV7-V data 1x 12 V connection for CV7-V power supply Galvanic isolation betwen power supply and analog outputs Galvanic isolation betwen power supply and sensor's power supply The sensor input is optocoupled. 420 AC This option features : 1 4-20 mA output loop current for wind speed ranging from 0.25 Kts to 80 Kts and CV7 measurement check. 1 4-20 mA output loop current for wind direction ranging from 0 to 359° and CV7 measurement check. 2 Dry contacts for wind speed alarm ANA-AC This option features 3 outputs 0-10V: 0-15m/s 0-30m/s or 0-40m/s selectable 0-359° wind direction.
