F3833 Bending Beam F3833 Double Ended Bending Beam Load Cell Size and Capacity F3833 Double Ended Bending Beam Load Cell Features & Applications Double Ended Bending Beam Load Cell, it belongs to Compression Load Cell. It is made of Stainless steel The protection class is IP68, waterproof. The capacity of anti deviated load and impact is very strong. It is welded-on metal bellows, it is available in the capacities 5kg to 500kg. It comes with complete 3.0m cable. Compact structure, it belongs to high capacities with low profile. Can be used for Truck scales, rail scales, Hopper, tank weighing and Chemical, Industries of Foods, Pharmaceuticals, which has huge important on weighing and control. F3833 Double Ended Bending Beam Load Cell Technical Parameters
Specifications
Technique
Rated output
2.0 ± 1% mV/V
Zero balance
± 2 % F.S.
Non-linearity
0.02% F.S.
Hysteresis
Repeatability
Creep (30min)
0.03% F.S.
Temp.effect on output
0.03% F.S. / 10°C
Temp.effect on zero
Input impedance
385 ± 10
Output impedance
350 ± 5
Insulation
5000M/100VDC
Recommended excitation
10V
Maximum excitation
15V
Compensated temp range
- 10 ~ 60 °C
Operation temp range
- 20 ~ 80 °C
Safe overload
150% F.S.
Ultimate overload
200% F.S.
Cable size
Ø5×3000 mm
Protection class
IP 68
Cable color code
Input: Red(+) Black(-); Output: Green(+) White(-);
