F1815 Compression Load Cell F1815 Compression Load Cell Size and Capacity F1815 Compression Load Cell Features & Applications Miniature load cell with metal foil strain gauge technology. Made of stainless steel. Designed for low profile compression service. There is an adjustable resistance outside the load cell. lts capacities range from 5Kg to 200kg It comes complete with 3m of load cell cable. The diameter is 13mm. Suitable for force measurement in limited spaces. Various applications such as consumer electronics assembly, automation industry. F1815 Compression Load Cell Technical Parameters
Specifications
Technique
Rated output
1.5±10% mV / V
Non-linearity
0.5 % F.S.
Hysteresis
Repeatability
0.1 % F.S.
Temp.effect on output
0.36 % F.S. / 10ºC
Temp.effect on zero
0.18 % F.S. / 10ºC
Input impedance
350±10
Output impedance
350±5
Insulation
5000M/100VDC
Recommended excitation
5 V
Maximum excitation
7 V
Compensated temp range
-10 ~ 60ºC
Operation temp range
-20 ~ 80ºC
Safe overload
120% F.S.
Ultimate overload
150 % F.S.
Cable size
Ø2×3000 mm
Protection class
IP64
Cable color code
Input: Red(+) Black(-); Output: Green(+) White(-);
