SE 656 Toroidal Conductivity Sensor
SE 656 Toroidal Conductivity Sensor Specifications
Cell factor
Approx. 2/cm ( 30 mm distance to wall)
Measuring range
0.002 to 2000 mS/cm
Accuracy
± (5 µS/cm +0.5 % measured value) at 20 °C +100 °C
± (10 µS/cm +0.5 % measured value) at >100 °C
Material
Cell:PFA ; Gasket:FFKM (Chemraz)
Temperature detector
Pt 100 (Class A)
Temp. response time t90
Approx. 11 min
Temperature
-20 +125 °C
Pressure
0 ... 16 bar
Cable
Fixed cable, 5 m
Protection
IP 68 (when mounted)
Assembly
G 3/4" (36-mm nut and FFKM (Chemraz) gasket included in shipment)
ATEX Certificate (SE 656 X)
II 1 G Ex ia IIC T4/T6 Ga
