SE 670 Toroidal Conductivity Sensor
Competitively priced digital sensor for measuring low to very high conductivity values, insensitive to contamination and corrosion
Universal conductivity sensor with large measuring range for moderate chemical stress. With integrated, extremely fast temperature detector.
SE 670 Toroidal Conductivity Sensor Facts
- Digital data transfer
- Cable length up to 100 m
- Competitively priced
- Compact design
- No process-wetted electrodes
- Large measuring range
- Quick-reacting temperature detector
- Insensitive to deposits and contaminations
SE 670 Toroidal Conductivity Sensor Applications
Fresh water and wastewater treatment, electroplating, photographic processes, air conditions, cooling tower monitoring, in-company wastewater treatment plants, monitoring of salts, alkaline solutions, and conductivity, tanneries, caustic treatment, washers, automotive engineering, rinsing processes
SE 670 Toroidal Conductivity Sensor Specifications
|
Cell factor*) |
Approx. 6.4/cm |
|
Measuring range |
0.02 to 2000 mS/cm |
|
Accuracy |
1 % |
|
Material |
PP (polypropylene) |
|
Temperature detector |
Pt 1000 |
|
Temperature response time |
Quick, using extrapolation with neuronal process |
|
Temperature |
0 60 °C (momentarily 100 °C) |
|
Pressure |
Max. 10 bar at 20 °C, max. 6 bar at 60 °C |
|
Process adaptations |
Coupling nut, G 1 1/2
Dairy pipe screw joint, DN 50
Replacement sensor for installation in
ARF 210/215 or ARD 220
|
|
Sensor cap |
M12 |
*) Observe instructions for use (field conditions)
