Ultra-Low Power Analog Sensor Module For Ethanol

Product Attribute:

Applicationt:

-

Production Description:

Ultra-Low Power Analog Sensor Module for Ethanol APPLICATIONS:

•  Law Enforcement Breathalyzers
•  Evidential Breath Alcohol Testing
•  Portable Breath Alcohol Tester
•  Personal Breathalyzers

Ultra-Low Power Analog Sensor Module for Ethanol BENEFITS:

•  0 to 3 V Analog Signal Output
•  Low Power Consumption < 45 µW
•  Fast Response
•  On-board Temperature Sensor
•  Easy Sensor Replacement
•  Standard 8-pin connector

Ultra-Low Power Analog Sensor Module for Ethanol DESCRIPTION:
    Quickly integrate Breath Alcohol or Ethanol Sensing into your system with very low power consumption and a simple analog sensor signal output.
    The ULPSM converts the Ethanol sensors linear current signal output to a linear voltage signal, while maintaining the sensor at its ideal biased operation settings.

MEASUREMENT PERFORMANCE CHARACTERISTICS:

Measurement Range	0 to 200 ppm
Lower Detection Limit	0.2 ppm
Resolution	0.2 ppm
Accuracy	< ± 2 % of reading
Response Time T90	< 60 seconds
Power-On Stabilization Time	15 minutes recommended

PACKAGE OUTLINE DRAWING & DIMENSIONS
